Summary

From the Computing History website: "The 1701 monitor has a composite input for the Vic 20, or for an even better picture for the C64, C16 and Plus 4, there is a chrominance and luminance output. It is virtually identical to the 1702, the only difference being the 1701 has a 5 pin din plug to the 1702s 8 pin one."

Manuals

• Owner's Manual
• Service Manual

Notes

This unit predates the s-video connector, but accepts separate luma and chroma. Adapters do exist to convert it into a standard s-video connector.
