| Specifications | |
|---|---|
| Brand: | Compaq |
| Manufacturer: | Lite-On |
| Model: | 5500 |
| Series: | Color Monitor |
| Viewable Size: | 14" |
| Input Signals: | Analog RGB |
| Sync: | HV Sync |
| Native Resolutions: | VGA, SVGA, XGA |
| Horizontal Scan Range: | 28 kHz, 54 kHz |
| Vertical Scan Range: | 48 Hz, 160 Hz |
| Aspect: | 4:3 |
| Adjustments: | OSD Customer Controls |
| Vertical Output IC: | TDA4863AJ |
| Flyback: | C1554MNSL |
| Tube: | M36AJA83X46 , M36AJA83X |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Shadow
|
| Pitch: | 0.28 mm |
| Tint: | Dark, Matte Anti-Glare |
| Removable Glare Film: | No |
| Yoke: | JAV-5301C1 |
| Yoke Horz. Inductance: | 0.2571 mH (@ 10 kHz) |
| Yoke Vert. Inductance: | 5.253 mH (@ 100 Hz) |
| Yoke Horz. Resistance: | 0.753 ohm |
| Yoke Vert. Resistance: | 10.92 ohm |
| Speakers: | None |
| Weight: | 29 lbs (13.2 kg) |
| Dimensions (W/H/D): |
365 x 400 x 418 mm
(14.3 x 15.7 x 16.4") |
| Application: | Computer Monitor |
| Cabinet Material: | Plastic |
| Launched: | 2002 |
| Country of Manufacture: | China |
| Mounting: | Desk Stand |
| Degaussing: | Automatic on Power-on, Manual |
