| Specifications | |
|---|---|
| Brand: | Compaq |
| Manufacturer: | ADI Corporation |
| Model: | V70 |
| Series: | Color Monitor |
| Viewable Size: | 16" |
| Inputs: | VGA |
| Sync: | HV Sync |
| Native Resolutions: | VGA, SVGA, XGA |
| Horizontal Scan Range: | 30 kHz, 69 kHz |
| Vertical Scan Range: | 50 Hz, 100 Hz |
| Aspect: | 4:3 |
| Adjustments: | Internal Potentiometers, External Potentiometers, OSD Customer Controls |
| Flyback: | TAD53617 |
| Tube: | Hitachi , M41KWB180X44 , M41KWB180X |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Shadow
|
| Pitch: | 0.28 mm, .28 mm |
| Tint: | Dark, Matte Anti-Glare |
| Removable Glare Film: | No |
| Yoke: | 89211266 |
| Yoke Horz. Inductance: | 0.17729 mH (@ 10 kHz) |
| Yoke Vert. Inductance: | 4.807 mH (@ 100 Hz) |
| Yoke Horz. Resistance: | 0.38 ohm |
| Yoke Vert. Resistance: | 7.77 ohm |
| Speakers: | None |
| Weight: | 38.4 lbs (17.4 kg) |
| Dimensions (W/H/D): |
421 x 440 x 440 mm
(16.5 x 17.3 x 17.3") |
| Application: | Computer Monitor |
| Cabinet Material: | Plastic |
| Launched: | 1996 |
| Country of Manufacture: | Thailand |
| Mounting: | Desk Stand |
| Degaussing: | Automatic on Power-on, Manual |
