Gallery
| Specifications | |
|---|---|
| Brand: | Daewoo |
| Manufacturer: | Daewoo |
| Model: | 905DF |
| Series: | XGA Color Monitor |
| Viewable Size: | 18" |
| Input Signals: | Analog RGB |
| Sync: | HV Sync, CSYNC |
| Native Resolutions: | VGA, SVGA, XGA, SXGA, UXGA |
| Horizontal Scan Range: | 30 kHz, 95 kHz |
| Vertical Scan Range: | 50 Hz, 160 Hz |
| Aspect: | 4:3 |
| Adjustments: | Internal Potentiometers, OSD Customer Controls |
| Tube: | Samsung , M46QCK761X , M46QCK761X123 |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Shadow
|
| Pitch: | 0.25 mm, .25 mm |
| Tint: | Dark, Matte Anti-Glare |
| Removable Glare Film: | No |
| Yoke: | DMX-1992ATS |
| Yoke Horz. Inductance: | 0.10353 mH (@ 10 kHz) |
| Yoke Vert. Inductance: | 4.825 mH (@ 100 Hz) |
| Yoke Horz. Resistance: | 0.37 ohm |
| Yoke Vert. Resistance: | 11.89 ohm |
| Speakers: | None |
| Chassis: | 905D |
| Weight: | 48 lbs (21.8 kg) |
| Dimensions (W/H/D): |
466 x 476 x 465 mm
(18.3 x 18.7 x 18.3") |
| Application: | Computer Monitor |
| Cabinet Material: | Plastic |
| Launched: | 2001 |
| Country of Manufacture: | Korea |
| Market: | North America |
| Power Standard: | 120v, 240v, 100v |
| Mounting: | Desk Stand |
| Degaussing: | Automatic on Power-on, Manual |
| Tag: | Needs Owners Manual |
