| Specifications | |
|---|---|
| Brand: | Dell |
| Manufacturer: | Philips |
| Model: | E771p |
| Series: | E |
| Viewable Size: | 16" |
| Input Signals: | Analog RGB |
| Sync: | HV Sync, CSYNC |
| Native Resolutions: | VGA, SVGA, XGA, SXGA |
| Horizontal Scan Range: | 28 kHz, 71 kHz |
| Vertical Scan Range: | 162 Hz, 46 Hz |
| Aspect: | 4:3 |
| Adjustments: | OSD Customer Controls, Software Calibration |
| Flyback: | AT2097/19A |
| Tube: | Chunghwa , M41AGE83X46 , M41AGE83X |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Shadow
|
| Pitch: | 0.27 mm |
| Tint: | Dark, Matte Anti-Glare |
| Removable Glare Film: | No |
| Yoke: | JNY-7701C1 |
| Yoke Horz. Inductance: | 0.18527 mH (@ 10 kHz) |
| Yoke Vert. Inductance: | 5.647 mH (@ 100 Hz) |
| Yoke Horz. Resistance: | 0.584 ohm |
| Yoke Vert. Resistance: | 10.25 ohm |
| Speakers: | None |
| Chassis: | CM2317P |
| Weight: | 33 lbs (15 kg) |
| Application: | Computer Monitor |
| Cabinet Material: | Plastic |
| Launched: | 2001 |
| Country of Manufacture: | Mexico |
| Mounting: | Desk Stand |
| Degaussing: | Automatic on Power-on, Manual |
| Tag: | Needs Measurements, Needs Owners Manual, Needs Service Manual |
