Dell M770

Matt Ross
October 31, 2024, 4:31 am
December 25, 2024, 12:33 am

Summary

17" CRT computer monitor, manufactured by Philips and sold under the Dell brand. A typical 70 kHz monitor, it's best used with 1024x768 at 85 Hz.

Specifications
Brand:	Dell
Manufacturer:	Philips
Model:	M770
Series:	M
Viewable Size:	16"
Inputs:	VGA
Sync:	HV Sync
Native Resolutions:	VGA, SVGA, XGA, SXGA
Horizontal Scan Range:	28 kHz, 71 kHz
Vertical Scan Range:	46 Hz, 167 Hz
Aspect:	4:3
Adjustments:	OSD Customer Controls
Tube:	Hitachi , M41KWB680X , M41KWB680X74
Heater Voltage:	6.3v
Deflection:	90°
Mask:	Shadow
Pitch:	0.28 mm
Tint:	Dark, Matte Anti-Glare
Removable Glare Film:	No
Yoke:	DSE-1422FL, 89-21189-6
Yoke Horz. Inductance:	0.13905 mH (@ 10 kHz)
Yoke Vert. Inductance:	4.773 mH (@ 100 Hz)
Yoke Horz. Resistance:	0.390 ohm
Yoke Vert. Resistance:	7.91 ohm
Speakers:	None
Chassis:	CM2317
Weight:	35.5 lbs (16.1 kg)
Application:	Computer Monitor
Cabinet Material:	Plastic
Launched:	1999
Country of Manufacture:	Taiwan
Mounting:	Desk Stand
Degaussing:	Automatic on Power-on, Manual
Tag:	Needs Owners Manual, Needs Service Manual, Needs Measurements, Needs Pictures
