| Specifications | |
|---|---|
| Brand: | Durabrand |
| Manufacturer: | Funai |
| Model: | DWT1304 |
| Series: | Durabrand |
| Viewable Size: | 13" |
| Inputs: | Composite, RF |
| Native Resolutions: | 240p, 480i |
| Horizontal Scan Range: | 15 kHz |
| Vertical Scan Range: | 60 Hz |
| Formats: | NTSC |
| Aspect: | 4:3 |
| Adjustments: | OSD Customer Controls, OSD Service Menu |
| Vertical Output IC: | LA78040 |
| Jungle IC: | M61203FP |
| Focus Type: | Single |
| Tube: | Funai , A34KQW42X |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Slot
|
| Pitch: | 0.64 mm |
| Tint: | Light |
| Removable Glare Film: | No |
| Yoke: | LLBY00ZMS006, LLBY00ZSY002, LLBY00ZSM004 |
| Speakers: | Mono, Headphone Jack, 1W |
| Remote: | NE142UD, NE154UD |
| Weight: | 19 lbs (8.6 kg) |
| Dimensions (W/H/D): |
323 x 358 x 367 mm
(12.7 x 14.1 x 14.4") |
| Application: | Consumer |
| Cabinet Material: | Plastic |
| Launched: | 2005 |
| Country of Manufacture: | Malaysia |
| Market: | North America |
| Power Standard: | 120v |
| Mounting: | Desk Stand |
| Degaussing: | Automatic on Power-on |
| Tag: | Community Submission |
