| Specifications | |
|---|---|
| Brand: | Goldstar |
| Manufacturer: | LG |
| Model: | 1505 |
| Series: | SVGA Monitor |
| Viewable Size: | 14" |
| Inputs: | VGA |
| Sync: | HV Sync |
| Native Resolutions: | VGA, SVGA, XGA |
| Horizontal Scan Range: | 25 kHz, 52 kHz |
| Vertical Scan Range: | 85 Hz, 45 Hz |
| Aspect: | 4:3 |
| Adjustments: | Internal Potentiometers, External Potentiometers |
| Vertical Output IC: | TDA8172 |
| Flyback: | 154-218D |
| Tube: | M36LBL803X , Goldstar , M36LBL803X31 |
| Deflection: | 90° |
| Mask: |
Shadow
|
| Pitch: | 0.28 mm, .28 mm |
| Tint: | Dark, Matte Anti-Glare |
| Removable Glare Film: | No |
| Yoke: | 153-183B |
| Yoke Horz. Inductance: | 0.18420 mH (@ 10 kHz) |
| Yoke Vert. Inductance: | 5.284 mH (@ 100 Hz) |
| Yoke Horz. Resistance: | 0.56 ohm |
| Yoke Vert. Resistance: | 9.12 ohm |
| Speakers: | None |
| Chassis: | CA-35 |
| Weight: | 29.2 lbs (13.2 kg) |
| Application: | Computer Monitor |
| Cabinet Material: | Plastic |
| Country of Manufacture: | Korea |
| Mounting: | Desk Stand |
| Degaussing: | Automatic on Power-on |
| Tag: | Needs Owners Manual, Needs Service Manual |
