HP A7217A (GDM-FW9012)
agfa
May 7, 2025, 4:08 pm
May 7, 2025, 4:08 pm
Summary
HP rebadge of the famous GDM-FW900 built by Sony
Notes
It has been observed that the plastic on the HP variant tends to stick on the seam between the bezel and the rear case, making it difficult to remove without damage. Plastic tools or improvised tools such as guitar picks or credit cards are crucial for opening the seam delicately.
Gallery



Specifications | |
---|---|
Brand: | HP |
Manufacturer: | Sony |
Model: | A7217A, GDM-FW9012 |
Viewable Size: | 22.5" |
Inputs: | VGA, BNC |
Sync: | HV Sync, CSYNC, Sync on Green |
Native Resolutions: | QHD |
Horizontal Scan Range: | 30 kHz, 121 kHz |
Vertical Scan Range: | 160 Hz, 48 Hz |
Aspect: | 16:10 |
Adjustments: | OSD Customer Controls, WinDAS |
Flyback: | NX-4504, J1D4 |
Focus Type: | Dual |
Tube: | Sony FD Trinitron , M57LRX15X |
Deflection: | 90° |
Mask: |
Aperture Grille
![]() |
Pitch: | 0.27 mm, 0.23 mm |
Tint: | Matte Anti-Glare, Light |
Removable Glare Film: | Yes |
Speakers: | None |
Chassis: | G1W |
Weight: | 92 lbs (41.7 kg) |
Dimensions (W/H/D): |
571 x 500 x 522 mm
(22.4 x 19.7 x 20.5") |
Application: | Computer Monitor |
Cabinet Material: | Plastic |
Launched: | 1999 |
MSRP: | 1999 USD |
Country of Manufacture: | Japan |
Market: | Worldwide |
Power Standard: | Universal |
Mounting: | Desk Stand |
Degaussing: | Automatic on Power-on, Manual |
