Summary

The JVC TM-1000PS is a 10-inch professional color video monitor designed for broadcast and video production environments. It features a high-quality CRT with a 0.47mm dot pitch, supporting PAL and SECAM color systems. The monitor offers over 300 lines of horizontal resolution and operates with a horizontal scan frequency of 15.625 kHz and a vertical frequency of 50 Hz. It includes multiple analog inputs such as composite and S-Video, along with termination switches for input flexibility. The unit provides front panel controls for volume, chroma, brightness, contrast, and synchronization adjustments, making it suitable for detailed video monitoring tasks. The TM-1000PS is built for reliability with a robust design and integrated speaker, supporting both AC and DC power sources, making it versatile for studio and field use.

Source: JVC TM-1000PS Service Manual, Victor Company of Japan, 1990

Manuals & Promo Materials

• Service Manual

Notes

Although the JVC TM-1000PS service manual specifies support for a 50 Hz vertical scan frequency typical of PAL video systems, the monitor can also handle PAL60 signals. Additionally, based on information in the service manual, with certain modifications it would be possible to enable NTSC compatibility.
