| Specifications | |
|---|---|
| Brand: | Montgomery Ward |
| Manufacturer: | Montgomery Ward |
| Model: | GEN 12114 |
| Series: | GEN |
| Viewable Size: | 9" |
| Input Signals: | RF |
| Native Resolutions: | 240p, 480i |
| Horizontal Scan Range: | 15 kHz |
| Vertical Scan Range: | 60 Hz |
| Formats: | NTSC |
| Aspect: | 4:3 |
| Adjustments: | Internal Potentiometers, External Potentiometers |
| Horz. Output Transistor: | 2SD1142 |
| Vertical Output IC: | LA7800 |
| Jungle IC: | UPC1352C |
| Flyback: | FB169, J11601 |
| Focus Type: | Single |
| Tube: | 270AEB22 |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Slot
|
| Removable Glare Film: | No |
| Yoke: | DY-140a, J261484 |
| Yoke Horz. Inductance: | 7.65 mH (@ 10 kHz) |
| Speakers: | Mono, Headphone Jack |
| Application: | Consumer |
| Cabinet Material: | Plastic |
| Launched: | 1983 |
| Country of Manufacture: | Taiwan |
| Market: | North America |
| Power Standard: | 120v |
| Mounting: | Table Surface (Standard) |
| Degaussing: | Automatic on Power-on |
| Tag: | Needs Owners Manual, Needs Service Manual, Needs Measurements, Needs Yoke Info |
