Summary
YOU MAY HAVE BOUGHT YOUR LAST COLOR TELEVISION
Same tube as the PVM 2530 but in a consumer chassis. The sales brochure mentions Velocity Modulation - unsure if and how this can be disabled but it is undesirable for gaming.
Literature
Notes
Came in two different colorways - Beige/Grey and Plum/Grey.
The RGB input is a 34 pin variant which is different from the 25 pin version found on other Sonys of this generation. The pinout is available in the service manual.
Gallery
| Specifications | |
|---|---|
| Brand: | Sony |
| Manufacturer: | Sony |
| Model: | KV-25XBR |
| Series: | XBR |
| Viewable Size: | 25" |
| Inputs: | Composite, RF, RGB, Digital RGB |
| Sync: | HV Sync, CSYNC, Sync on Green, Sync over Composite, Sync on Luma |
| Resolutions: | 240p, 480i |
| Linecount: | 400 TVL |
| Horizontal Scan Range: | 15 kHz |
| Formats: | NTSC |
| Aspect: | 4:3 |
| Adjustments: | Internal Potentiometers, OSD Customer Controls |
| Tube: | Sony Microblack Trinitron , A64JKJ10X |
| Heater Voltage: | 6.3v |
| Deflection: | 114° |
| Mask: |
Aperture Grille
|
| Pitch: | 0.73 mm |
| Tint: | Dark |
| Speakers: | Amplifier, APM-X3U |
| Remote: | RM-724 |
| Chassis: | P2B |
| Weight: | 99 lbs (45 kg) |
| Application: | Consumer |
| Launched: | 1984 |
| Country of Manufacture: | Japan |
| Mounting: | Floor Stand, SU-171, SU-172, SU-173 |
| Degaussing: | Automatic on Power-on |
