Gallery
| Specifications | |
|---|---|
| Brand: | Sylvania |
| Manufacturer: | KDS |
| Model: | F77 |
| Series: | F |
| Viewable Size: | 16" |
| Inputs: | VGA |
| Sync: | HV Sync |
| Native Resolutions: | VGA, SVGA, XGA, SXGA |
| Horizontal Scan Range: | 30 kHz, 70 kHz |
| Vertical Scan Range: | 50 Hz, 160 Hz |
| Aspect: | 4:3 |
| Adjustments: | OSD Customer Controls |
| Vertical Output IC: | TDA8172 |
| Flyback: | LCE CF1635 |
| Tube: | M41AGE83X , M41AGE83X76 |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Shadow
|
| Pitch: | 0.28 mm |
| Tint: | Dark, Matte Anti-Glare |
| Removable Glare Film: | No |
| Yoke: | JNY-7702C1 |
| Yoke Horz. Inductance: | 0.13904 mH (@ 10 kHz) |
| Yoke Vert. Inductance: | 5.965 mH (@ 100 Hz) |
| Yoke Horz. Resistance: | 0.43 ohm |
| Yoke Vert. Resistance: | 10.93 ohm |
| Speakers: | None |
| Chassis: | C718 |
| Weight: | 34 lbs (15 kg) |
| Application: | Computer Monitor |
| Launched: | 2000 |
| Country of Manufacture: | China |
| Degaussing: | Automatic on Power-on, Manual |
