| Specifications | |
|---|---|
| Brand: | Symphonic |
| Manufacturer: | Funai |
| Model: | SC313E |
| Series: | TV/VCR Combo |
| Viewable Size: | 13" |
| Inputs: | Composite, RF |
| Native Resolutions: | 240p, 480i |
| Horizontal Scan Range: | 15 kHz |
| Vertical Scan Range: | 60 Hz |
| Formats: | NTSC |
| Aspect: | 4:3 |
| Adjustments: | OSD Customer Controls, OSD Service Menu |
| Horz. Output Transistor: | 2SC5884000RF |
| Vertical Output IC: | LA78040A |
| Jungle IC: | M61275FP-661 |
| Flyback: | JF0501-3101B |
| Focus Type: | Single |
| Tube: | A34AGT13X |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Slot
|
| Tint: | Dark |
| Removable Glare Film: | No |
| Yoke: | LLBY00ZSY005 |
| Speakers: | Headphone Jack, 2W |
| Remote: | N0107UD, N0150UD |
| Weight: | 23.1 lbs (10.5 kg) |
| Dimensions (W/H/D): |
367 x 389 x 377 mm
(14.4 x 15.3 x 14.8") |
| Application: | Consumer |
| Cabinet Material: | Plastic |
| Launched: | 2004 |
| Country of Manufacture: | Malaysia |
| Market: | North America |
| Power Standard: | 120v |
| Mounting: | Table Surface (Standard) |
| Degaussing: | Automatic on Power-on |
| Tag: | Community Submission |
