Gallery
| Specifications | |
|---|---|
| Brand: | Toshiba |
| Manufacturer: | Orion |
| Model: | MW20F52 |
| Series: | MW |
| Viewable Size: | 20" |
| Inputs: | Composite, RF |
| Native Resolutions: | 240p, 480i |
| Horizontal Scan Range: | 15 kHz |
| Vertical Scan Range: | 60 Hz |
| Formats: | NTSC |
| Aspect: | 4:3 |
| Adjustments: | OSD Customer Controls, OSD Service Menu |
| Horz. Output Transistor: | D2499 |
| Vertical Output IC: | LA78040 |
| Jungle IC: | LA76319NM-MPB-E |
| Comb Filtering: | 3-Line Digital |
| Comb Filter IC: | LA76606M-TLM-E |
| Flyback: | FJN20A003_M |
| Tube: | A51QDJ420X , A51QDJ420X58 |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Slot
|
| Tint: | Dark |
| Removable Glare Film: | No |
| Yoke: | 6150Z-1228H |
| Yoke Horz. Inductance: | 1.5928 mH (@ 10 kHz) |
| Yoke Vert. Inductance: | 23.99 mH (@ 100 Hz) |
| Yoke Horz. Resistance: | 3.06 ohm |
| Yoke Vert. Resistance: | 12.00 ohm |
| Speakers: | Stereo |
| Remote: | WC-SBU2 |
| Weight: | 59.5 lbs (27 kg) |
| Application: | Consumer |
| Launched: | 2006 |
| Country of Manufacture: | Thailand |
| Degaussing: | Automatic on Power-on |
