Summary
Standard flat tube 17" PC monitor, from budget computer manufacturer eMachines. Similar in specs to most other monitors of its day, it has a 70 kHz max scan rate and is intended to be used in 1024x768 at 85 kHz.
Manuals
Notes
This monitor appears to be identical to the AOpen A70PF.
Gallery
| Specifications | |
|---|---|
| Brand: | eMachines |
| Manufacturer: | Proview Electronics |
| Model: | 17f3 |
| Series: | eView |
| Viewable Size: | 16" |
| Inputs: | VGA |
| Sync: | HV Sync |
| Native Resolutions: | VGA, SVGA, XGA, SXGA |
| Horizontal Scan Range: | 30 kHz, 71 kHz |
| Vertical Scan Range: | 50 Hz, 160 Hz |
| Aspect: | 4:3 |
| Adjustments: | OSD Customer Controls |
| Vertical Output IC: | STV9302A |
| Flyback: | FWK0392 |
| Tube: | Samsung , M41QCJ761X , M41QCJ761X172 |
| Heater Voltage: | 6.3v |
| Deflection: | 90° |
| Mask: |
Shadow
|
| Pitch: | 0.25 mm, .25 mm |
| Tint: | Dark |
| Removable Glare Film: | No |
| Yoke: | E210439 |
| Speakers: | None |
| Weight: | 33.5 lbs (15.2 kg) |
| Dimensions (W/H/D): |
406 x 410 x 420 mm
(16 x 16.1 x 16.5") |
| Application: | Computer Monitor |
| Cabinet Material: | Plastic |
| Launched: | 1999 |
| Country of Manufacture: | China |
| Mounting: | Desk Stand |
| Degaussing: | Automatic on Power-on, Manual |
| Tag: | Needs Service Manual |
