Summary
Rebadged JVC TM-910SU with S-Video input.
Manuals
Notes
The jungle chip used on this monitor does not have RGB inputs. As this monitor is the same as the JVC TM-910SU, see that page for further documentation.
Repair Notes
- Wouldn't turn on: C919 and C929 on sub power board 2
- Vertical collapse & foldover: C416 and C413 on main board
- Uneven brightness, brighter on the left side and darker on the right side: C522 open on main board
Other capacitors that tested high ESR on the main board and neck board: C306, C310, C519, C533, C613, et al.
Gallery
| Specifications | |
|---|---|
| Brand: | Panasonic |
| Manufacturer: | JVC |
| Model: | BT-S950P |
| Series: | BT |
| Viewable Size: | 9" |
| Inputs: | Composite, S-Video |
| Sync: | CSYNC, Sync over Composite, Sync on Luma |
| Native Resolutions: | 240p, 480i, 288p, 576i |
| Linecount: | 280 TVL |
| Horizontal Scan Range: | 15 kHz |
| Formats: | NTSC, PAL |
| Aspect: | 4:3 |
| Adjustments: | Internal Potentiometers, External Potentiometers, Front Mounted Buttons |
| Horz. Output Transistor: | 2SD1878-YD |
| Vertical Output IC: | LA7830 |
| Jungle: | Panasonic, AN5613 |
| Comb Filtering: | Glass |
| Flyback: | CJ28347-00B |
| Focus Type: | Single |
| Tube: | Panasonic , A22JWG098X |
| Deflection: | 90° |
| Mask: |
Slot
|
| Pitch: | 0.5 mm |
| Tint: | Dark |
| Yoke: | CE20300-00A |
| Yoke Horz. Resistance: | 5.5 ohm, 5.50 ohm |
| Yoke Vert. Resistance: | 15.1 ohm |
| Speakers: | Mono, 1W |
| Chassis: | B10 |
| Weight: | 16 lbs (7.3 kg) |
| Dimensions (W/H/D): |
222 x 236 x 317 mm
(8.7 x 9.3 x 12.5") |
| Application: | Professional |
| Cabinet Material: | Metal |
| Launched: | 1998 |
| MSRP: | 800 USD |
| Country of Manufacture: | Thailand |
| Power Standard: | 120v, 12VDC |
| Mounting: | Carrying Handle, Rackable |
| Degaussing: | Automatic on Power-on |
| Tag: | Needs Service Manual |
