Summary

Very large monitor using a fine pitch Trinitron in 1:1 aspect ratio, fixed 2K by 2K resolution. First shown in 1988 and intended for a wide array of applications that require displaying as much information as possible. Serviced until mid 2010s for air traffic control.

Was sold in two styles; a free-standing desktop monitor, and an industrial version meant to be semi-permanently installed.

Manuals

• Service Manual
• Owner's Manual (2801CU / 2802CU / 2802CNU / 2811CU)
• Owner's Manual (2800CSU / 2810CSU)

Notes

Using the DDM-RM10 wired remote, this monitor features extremely fine digital convergence control and digital focus control.
