Summary
13" TV/DVD combo, made by Orion with Toshiba branding.
Manuals
Media & Promo Materials
Notes
The set under test had noticeable ringing due to sharpness being too high at the midpoint level. Reducing sharpness all the way down addressed this.
There is a vertical position potentiometer on the main PCB. The DVD drive is internally connected via Y/C, and so the set can be S-Video modded. The OSD (user menu) unfortunately exhibits severe ringing, so while an RGB mux mod is doable, it's not particularly recommended.
Gallery
| Specifications | |
|---|---|
| Brand: | Toshiba |
| Manufacturer: | Orion |
| Model: | MD13Q41 |
| Series: | MD |
| Viewable Size: | 13" |
| Inputs: | Composite, RF |
| Native Resolutions: | 240p, 480i |
| Horizontal Scan Range: | 15 kHz |
| Vertical Scan Range: | 60 Hz |
| Formats: | NTSC |
| Aspect: | 4:3 |
| Adjustments: | OSD Customer Controls, OSD Service Menu |
| Horz. Output Transistor: | 2SC5885 |
| Vertical Output IC: | AN5522 |
| Jungle: | LA76319NM-MPB-E |
| Comb Filtering: | None |
| Flyback: | FNI-14B001 |
| Tube: | A34JXV70X , Thai CRT Co. , A34JXV70X73 |
| Deflection: | 90° |
| Mask: |
Slot
|
| Pitch: | .53 mm |
| Tint: | Dark |
| Yoke Horz. Resistance: | 6.5 ohm |
| Yoke Vert. Resistance: | 15.9 ohm |
| Speakers: | Stereo |
| Remote: | DC-SB1 |
| Weight: | 24.2 lbs (11 kg) |
| Application: | Consumer |
| Cabinet Material: | Plastic |
| Launched: | 2005 |
| MSRP: | 149 USD |
| Country of Manufacture: | Thailand |
| Mounting: | Carrying Handle |
| Mods: | RGB via Mux, S-Video |
| Degaussing: | Automatic on Power-on |
