Summary

13" model from Sony's flat screen Wega line, with RF and composite video inputs. One of three 13" Wega models sold at the time, it features an attractive dark blue case. The other two variants were the KV-13FM12 (silver) and KV-13FM13 (white).

Literature

• User Manual
• Service Manual
• BA-5 Chassis Repair Training Manual
• Sony Product Page

Notes

Unlike the 27" and larger BA-5 Trinitrons, this TV does not have native component inputs. However, its jungle chip is very versatile and can be modified for RGB and YPbPr component video. Please note that due to a different M board design and jungle chip, the RGB mod procedure for the 27" BA-5 Trinitrons doesn't apply.

RGB Multi-Mod Guide

S-Video mod instructions

The user menu includes a tilt control. To have a warmer color temperature closer to reference 6500K, in the service menu section VP2, set DCOL to 0 (instead of 1).

Composite 240p Performance

by Eli Krause

For composite decoding this set uses a Toshiba TC90A49P, a 3-line digital comb filter. Depending on the console/revision, dot artifacting ranges from slight to severe, and blending effects may be broken. If the set has a component YPbPr input on, then using a good external notch filter to decode composite instead (such as the one in a RetroTink 2X, 5X, etc.) and sending that to the component input would blend all dithering patterns and remove nearly all dot artifacts. A recommended no lag HDMI to component converter is available here (select the bypass version).
