Notes

• Adjusting the yoke on a flat CRT to fix bowing

Composite 240p Performance

by Eli Krause

For composite decoding this set uses a Toshiba TC90A49P, a 3-line digital comb filter. Depending on the console/revision, dot artifacting ranges from slight to severe, and blending effects may be broken. If the set has a component YPbPr input on, then using a good external notch filter to decode composite instead (such as the one in a RetroTink 2X, 5X, etc.) and sending that to the component input would blend all dithering patterns and remove nearly all dot artifacts. A recommended no lag HDMI to component converter is available here (select the bypass version).
